DACS Digital Audio Control System
Operators Manual
Rev: 1.00 Page 16
DACS_813-0100
CONFIDENTIAL AND PROPRIETARY TO COBHAM
4.2 Remote Alert Inhibit (not on ACP)
CAUTION:
When an Audio Alert Inhibit switch is activated, it is important to be aware that no
aural notification generated by the AMU will be given for any alert situation.
A remote Alert Inhibit switch may be installed in the aircraft. This switch is like an
on/off switch for the aural alerts generated by the AMU which in effect mutes all
tones/voice messages. Although the standard visual alerts will still be visible to the
pilot and copilot no other crew or passengers will receive audible notification of these
alerts.
4.3 Other Remote Switches (not on ACP)
Other remote switches and indicators may be installed. It is important to be
aware of the configuration set-up for your installation. Confirm the specific
criteria associated with this installation with your installing agency.
5 ACP53 Specifications
5.1 Electrical Specifications
Input Power 25.5 Vdc
0.25 A @ 25.5 Vdc
Lighting 27.5 Vdc
0.10 A @ 27.5 Vdc
Optional Panel Lights 5 Vdc
0.10 A @ 5 Vdc
These commodities, technology or software are controlled in accordance with the United States Export Administration Regulations, Export Classification
Control Number(ECCN) 7E994. When exporting, diversion contrary to U.S. law is prohibited.
