COBHAM SAILOR 7224 Installation Guide

Connections
Speaker Microphone
Control
Control Unit
GNSS (NMEA)
Speaker (8 ohm)
External
SAILOR 6204
SAILOR 6201/03
Ext. Connections
Ethernet
99-167111-A.10
SAILOR 7224
406209-940
Cable
406209-940
Cable
(without DSC)
LAN
24V DC
110/220V AC
Handset Option
ACC
Max 4 SAILOR 6204
SAILOR 6208
Connection Box
SAILOR 6208
Connection Box
SAILOR 6208
Connection Box
Power
Power Supply
SAILOR N163S
SAILOR 6208
Connection Box
SAILOR 6207
Connection Box
for Parallel Handsets
406208-941
Cable
AUX
CTRL
406209-941
Cable
24V DC
Alarm
DSC Call
AUX
GPS
VDR
Lo Pwr Forced
OPT LAN
BAM (NMEA)
LWE (GNSS/BAM)
LAN
SAILOR 6209
Accessory Connection Box
VHF Transceiver Unit
SAILOR 7226
SAILOR 6201/03
Handset Option
24V Battery
Antenna
DSC
Antenna
RX/TX
98-173211-B.03
www.cobhamsatcom.com
More details about installation, download the installation manual at www.cobhamsatcom.com
Disclaimer: Any responsibility or liability for loss or damage in connection with the use of this product and the accompanying documentation is disclaimed by Thrane & Thrane A/S. The information in
this installation guide is provided for information purposes only, is subject to change without notice and may contain errors or inaccuracies. The installation guides are periodically revised and updated.
Anyone relying on this information should acquire the most current version e.g. from cobham.com/satcom or from the distributor. Thrane & Thrane A/S is not responsible for the content or accuracy of any
translations or reproductions, in whole or in part, of this installation guide from any other source. Thrane & Thrane A/S trading as Cobham SATCOM. Copyright © 2021 Thrane & Thrane A/S. All rights reserved.
System Conguration - Example
Cut out - Flush mounting
Flush mount template
Remove material from shaded area only!
89mm
227mm
R2.5mm x 4
Drilling plan - U-mount bracket
99-131985
200mm
53mm
71mm
247mm
9mm
4 x M4 or hole for
self-tapping ø3.9
23.5mm
1. ACC connector for accessories
2. AUX connector for VDR, External speaker, DSC alarm, GPS input
3. OPT connector
4. CTRL connector for SAILOR 6204 Control Speaker Microphone
or SAILOR 6208 Connection Box
5. Ground stud for grounding
6. Power connector
7. LAN connectors for Ethernet and Ext. Connections
8. USB connector
1
2 3
4
5 6
7 8
