Tightening torques
Kategory Screw Tool Torque
front wheel axle screw Inbus 6mm 8Nm
rear wheel axle screw spanner 18mm 25Nm
handlebar / stem stem (steerer clamping) Inbus 5mm 5.2Nm
handlebar / stem stem (handlebar clamping) Inbus 4mm 5.2Nm
handlebar / stem cover steerer tube Inbus 5mm 0,5-1Nm
handlebar / stem brake lever (clamping) Inbus 5mm 6-8Nm
braking system caliper Inbus 5mm 5-7Nm
saddle saddle clamping Inbus 5mm 9Nm
saddle seatpost clamping Inbus 4mm 5Nm
mechanical drive chain ring Inbus 5mm 12Nm
mechanical drive crank Inbus 8mm 40Nm
mechanical drive derailleur Inbus 5mm 10Nm
attachment parts pedals Inbus 6 mm 35Nm
attachment parts kickstand Inbus 5 mm 6Nm
front fender fork dropout attachment Inbus 3 mm 2-2.5Nm
front fender fork crown attachment Inbus 4 mm / spanner 10 mm 4Nm
rear fender attachment to frame and rack Inbus 3 mm 2-2.5Nm
rack attachment seat stay Inbus 4 mm 4Nm
rack attachment dropout Inbus 4 mm 4Nm
