Cobra 2980 User Manual

9
®
English
Only cut out the positive on closing for the motor with negative polarity when
unused and both wires for the motor with positive polarity when unused.
LAYOUT C
Layout to use for:
- systems where there is no polarity on the unused window winding motors
- systems with a positive common contact
- whenever there is no difficulty in understanding the mode of the electric
window winding system
Cut out both wires that power the motor.
TECHNICAL SPECIFICATIONS
Voltage rating .............................................................................. 12 VDC
Operating power rating............................................................. 9/16 VDC
Power draw on hold...................................................................... 0.1 mA
Operating temperature ........................................................ -40°C/+85°C

Cobra 2980 Specifications

General

Brand	Cobra
Model	2980
Category	Control Unit
Language	English
