MANUAL TTL
(M)
MODE
Switch camera on and select manual (M) mode (refer to camera's
instruction book). Any combination of shutter speed (up to the maxi-
mum sync) and aperture may be selected. Refer to the scale (5) on the
rear of the gun to obtain maximum shooting distances.
SLOW-SHUTTER SYNC
50001,
70001,
80001,
2xi, SPxi, 5xi, 7xi, 9xi
Slow shutter sync is available on the above cameras. It allows you to
increase the background exposure for better background detail and
also creates a more natural lighting balance between the subject and
the background. Slow-shutter sync can be used in program (P) mode
with all the above cameras. For other modes consult your camera's
instruction book.
Select Program or desired mode available on your camera and switch
flash on. The above cameras will have either a SPOT button or an AEL
button located to the right of the viewfinder. When the flash has charged
a sync speed and aperture will be set by the camera. The pressing of
the SPOT/AEL button will cause the camera to set a slower speed (up
to slowest speed of particular model). Use a sturdy tripod with slower
speeds to avoid the danger of camera shake.
NOTE: The 700AF can be used in conjunction with certain Creative
Expansion Cards (available for some Dynax models). Simply mount the
flash and switch it on. The camera will select a shutter speed and
aperture according to the particular card being used. If in doubt refer to
your Minolta Dealer.
EXPOSURE CHECK
If the flash exposure is sufficient, the auto check indicator (9) will light
up briefly. If it fails to, check that you are within the maximum distance
by refering to the scale (5) on the rear of the gun. In aperture priority or
manual modes a larger aperture may be selected allowing more light to
strike the film.
PENTAX AF CAMERAS:
The 700AF can be used in the following exposure modes with the Z-1
and
Z-20.
"
GREEN SQUARE OPERATION
"
PROGRAMMED AE/PROGRAMMED
AE, HYPER PROGRAMMED AE (Z-1 only), SHUTTER-PRIORITY AE,
APERTURE-PRIORITY AE, HYPER
MANUAL.MANUAL
(BULB)
the following modes with the SF7, SFX, and SFX-N
PROGRAMMED AE, SHUTTER-PRIORITY AE, APERTURE-PRIOR-
ITY AE, METERED MANUAL
and the following modes with the
Z-10
PROGRAMMED AE, METERED MANUAL
"
GREEN SQUARE
"
PROGRAMMED
AE
MODE
(Z-1
&
Z-20),
PROGRAMMED
AE MODE (ALL MODELS)
Select PROGRAMMED AE mode on the camera (refer to camera's
instruction book), this is useful for general photography. In this mode
shutter sync speed and aperture are selected for you, any speed from
1/250th
sec to
1/30th
sec may be set depending on particular camera
model and ambient lighting. Switch flash on and wait for the ready
signal 7) to glow then simply point, focus and shoot.
Note: The 700AF will also operate with the
"
"
modes of the
Z-20. Refer to the Z-20's instruction book for further information.
HYPER PROGRAMMED AE MODE (Z-1 ONLY)
This mode is similar to standard program but the user has the option of
altering the shutter speed and aperture without switching modes. Se-
lect HYPER PROGRAMMED AE on the camera (refer to
camera's
instruction book). Initially a shutter sync speed and aperture combina-
tion will be set by camera. If desired this can be changed by using the
TV and AV input dials on the front and rear of the camera.
Note: a safety shift feature on the Z-1 will not allow incorrect shutter
speed
/aperture
combinations to be set. If this happens an
"
S
"
will
appear on the LCD information panel. For more information refer to the
camera's instruction book.
SHUTTER-PRIORITY AE MODE (ALL MODELS EXCEPT Z-10)
This mode allows the user to select any shutter speed from the maxi-
mum sync to the slowest speed. It is useful for increasing the back-
10
