Cobra 700AF User Manual

700AF PRO - GRIP
The 700AF PRO - GRIP is an optional accessory to your flashgun.
It comprises of a sturdy grip and bracket which enables the 700
AF to be used off-camera, giving much improved illumination to
portraits and other subjects. All the programmed dedication be-
tween camera and gun is retained. The AF illuminator remains
on the camera for accuracy and is connected to the flash with an
extension lead.
13
SPECIFICATIONS
Dedication
Guide Number
(ISO 100 in meters)
Angles of coverage
(VxH)
Film speed settings
Flash duration
Recycling time
Number of flashes
Power source
Accessories
: TTL operation for AF SLRs.
: 25 (28 mm zoom head position)
: 30 (35 mm zoom head position)
35 (50 mm zoom head position)
42 (85 mm zoom head position)
: 28 mm 53 x 70 deg
35 mm 45 x 60 deg
50 mm 34 x 46 deg
85 mm 23 x 31 deg
Marked for ISO 50 -1000
1/1000 to 1/30,000 sec.
0.5 to 12 sec.
Over 80 per new set of alkaline
batteries.
4 x AA size alkaline batteries or Nl-
CAD equivalent.
Wide-angle diffuser and three
colour filters.
Cobra Europe Limited
5 Capstan Centre, Thurrock Park Way,
Tilbury, Essex RM18 7HH,
England
Tel: (0375) 840540
14
Donated to www.orphancameras.com

Cobra 700AF Specifications

Guide Numbers

guide number at 28 mm zoom head position	25 (ISO 100 in meters)
guide number at 35 mm zoom head position	30 (ISO 100 in meters)
guide number at 50 mm zoom head position	35 (ISO 100 in meters)
guide number at 85 mm zoom head position	42 (ISO 100 in meters)

Angles of Coverage

angles of coverage at 28 mm	53 x 70 degrees (VxH)
angles of coverage at 35 mm	45 x 60 degrees (VxH)
angles of coverage at 50 mm	34 x 46 degrees (VxH)
angles of coverage at 85 mm	23 x 31 degrees (VxH)

Flash Specifications

film speed settings	ISO 50 - 1000
flash duration	1/1000 to 1/30, 000 sec
recycling time	0.5 to 12 sec
number of flashes per new set of alkaline batteries	Over 80

Power Source

power source	4 x AA size alkaline batteries
power source alternative	Ni-CAD equivalent
