Cobra HT50LRH24V - TECHNICAL DATA; ASSEMBLY; ATTACHING THE STANDARD HEDGE TRIMMER

9
4. TECHNICAL DATA
Model:
HT50LRH24V
Rated voltage:
24V DC
No Load Speed
Turbo 1300-1500r/min
Eco 1100-1300r/min
Cutting length
500mm
Cutting width
20mm
Net weight:
3.34kg
Battery:
24v 2.5Ah
5. ASSEMBLY
WARNING: Switch off and remove the battery from machine before adjusting or cleaning. The blades
continue to move for a fraction of a second after the hedge trimmer is switched off. Do not touch the moving
blades.
5.1 ATTACHING THE STANDARD HEDGE TRIMMER
The battery should be removed before proceeding:
Insert the hedge trimmer attachment into the
handle assembly of the tool. The electrical
connectors within the shafts will locate with a
positive click.
