3.3 FITTING THE SEAT
Mount the seat on the plate using the screws.(Use the open
end wrench 8-10 in accessories tools.
For optional seat only (if applicable):
a.
Fix the right armrest (1) on the seat with three M8 screws
(2) using the Allen wrench in accessories tools, and fix
the left armrest (3) on the seat in the same way;
b.
Snap the retaining ring (1) into the pin (2), use the pin to
link the seat (3) to the bracket, and snap it into the
retaining ring (4).
