A3
1
2
54
3
6
Thank you for purchasing the Cobra MicroTalk
2-way Radio. Properly used,this Cobra product
will give you many years of reliable service.
Co b ra on the Wo rld Wi d e
We b : Frequently Asked
Questions (FAQ) can be
found on-line at:
www.cobraelec.com
Controls and Indicators
A2
Controls and Indicators
1. Retractable Antenna
2. Belt Clip
3. On/Off Volume Control
4. Microphone Jack
5. Speaker Jack
6. Battery Charge Pads
7. TX (talk/Batt Low
(batteries are low)
Indicator
8. Call/Ring Button
9. Channel Select Buttons
10. Microphone
1 1 . Maximum Range
Extender Button
12 . PTT (Push To Talk ) Key
13 . Battery Chamber
1 0
1
7
8
9
1 1
1 3
1 2
PMR100-UK.qx copy 6/17/99 9:37 AM Page 20
