Adjusting for wear:
The Aerator is subject to wear in use due
to the way in which it works. The more
intensively the Aerator is used, the greater
the wear on the knives.
Hard or very dry ground accelerates wear
as does excessive use of the Aerator.
If the results of your work with the Aerator
become increasingly worse due to knife
wear, the aerator cylinder can be
adjusted by selecting different positions on
the lever.
The aerator cylinder has 4 adjustment
positions:
·Transport position 1
·Aerating position 2
·Aerating position 3
First adjustment position after knife wear
(aerator cylinder lowered by 3 mm)
·Aerating position 4 ：
Second adjustment position after knife
Wear
(aerator cylinder lowered by afurther 3mm)
Push wear compensation lever gently
away from the housing and move to the
position required.
Note: Wear adjustment is not used
for height adjustment. Adjustment
of the aerator cylinder without
visible wear can cause damage to
the aerator cylinder or overload the
motor.
