Page 18
SET UP & USE
ENGLISH
LED Display Indicators
Cooling mode Fan speed
Dehumidify mode Swing
Fan mode
Timer on
Heat mode
Heat model
CBPAC1080H only
Time
Sleep
Display temp. or
hours
• Press to Turn Air Conditioner ON or OFF. Press LED button to illuminate the
• Press the mode button to scroll through COOL , DRY , FAN , HEAT
• The corresponding symbol will illuminate on the LED display to indicate which
mode is selected.
•
Fahrenheit or
Celsius.
COOL
•
POWER BUTTON
LED screen on the unit.
MODE BUTTON
(Heat model CBPAC1080H only)
Select the target temperature 61˚F – 88˚F (16˚C – 31˚C) by pressing the
or buttons until the desired temperature is displayed on the LED screen.
Press the Fan Speed Button to select Low, Medium, or High Speed.
