Connect motor wiring
How to connect the motor wiring
depends on the type of motor:
- Read step 4A for a 230V motor.
- Read step 4B for a 12-24V motor.
- Read step 4C for a motor with a
momentary switch.
EN
4
HU
EL
DE
A motor vezetékezésének bekötése
A vezetékek bekötési módja függ a motor
típusától:
– A 230 voltos motorokkal a „4A szakasz
foglalkozik.
– A 12–24 voltos motorokkal a „4B” szakasz
foglalkozik.
– A pillanatkapcsolós motorokkal a „4C szakasz
foglalkozik.
Σύνδεση καλωδίωση οτέρ
Ο τρόπο σύνδεση τη καλωδίωση του
οτέρ εξαρτάται από τον τύπο του οτέρ:
- Για ένα οτέρ 230 V, διαβάστε το βήα 4Α.
- Για ένα οτέρ 12-24 V, διαβάστε το βήα 4Β.
- Για ένα οτέρ ε στιγιαίο διακόπτη, διαβάστε
το βήα 4C.
Motorkabel anschließen
Der Anschluss der Motorverkabelung hängt
vom Motortyp ab:
- Lesen Sie Schritt 4A für einen Motor mit 230 V.
- Lesen Sie Schritt 4B für einen Motor mit 12-24 V.
- Lesen Sie Schritt 4C für einen Motor mit Taster.
