Presentation
21. [ ] Volume key
22. [ ] Handsfree key
23. Microphone for handsfree mode
24. [ ] Silent mode key
25. DC 5V power connector
26. Base RJ9 connector
27. Wall mounting holes
28. Multi-position stand
29. Screws for Tablet locking / unlocking
12. Handset/Receiver
13. Handset RJ9 connector
14. ‘Type C’ USB data input port
15. Secured cable slot
16. Headphone / Handsfree jack connector
(CTIA)
17. External microphone jack connector
18. Speaker
19. Charging indicator
20. Handsfree indicator
29 29
13
12
15
18
19
25
2827
22
20
21
14
16
23
2624
17
