Specications
Siren Section
Input Voltage 10-16VDC (negative ground)
Input Current 17 Amps @ 13.6VDC (dual 100W speakers)
Standby Current Less than 180 mA, Less than 140 mA when Keypad lights turned off.
Output Voltage Maximum 200W @ 12VDC (dual 100W speakers)
Operating Temperature -30 °C to +65 °C
Dimensions (HWD):
Handheld controller 1.2”X2.4”X5.9”
Amplier 2.7″X6.2″X7.1″
Weight – Siren (approx): 4.0 lbs
Weight – Controller (approx): 0.5 lbs
Base: Black anodized
Mounting – Siren: 4-hole ange mounting on base & mounting hardware
Mounting – Controller: Cradle & mounting hardware
Compliance: SAE J1849, 2004/104/EC, California Title 13
Warranty: 5 years
Lighting Section
Warning Light Control 7 levels
Level 1 20A maximum
Level 2 20A maximum
Level 3 20A maximum
AUX 1 10A maximum
AUX 2 10A maximum
AUX 3 10A maximum
AUX 4 10A maximum
Maintenance
Your Code 3 siren has been designed to provide trouble free service. In case of difculty, consult the Troubleshooting Guide
of this manual. Also check for shorted or open wires. The primary cause of short circuits has been found to be wires passing
through rewalls, roofs, etc. If further difculty persists, contact the factory for troubleshooting advice or return instructions.
Public Safety Equipment, Inc. maintains a complete parts inventory and service facility at the factory and will repair or re-
place (at the factory’s option) any unit found to be defective under normal use and in warranty. Any attempt to service a unit
in warranty, by anyone other than a factory-authorized technician, without the express written consent of the factory, will
void the warranty.
Units out of warranty can be repaired at the factory for a nominal charge on either a at rate or parts and labor basis. Contact
the factory for details and return instructions. Public Safety Equipment, Inc. is not liable for any incidental charges related to
the repair or replacement of a unit unless otherwise expressly agreed to in writing by the factory.
Parts List
Part Number Description Quantity
T15060 Siren (Amplier) 1
T15061 Hand Held Controller with Coil Cord 1
T15062 Hand Held Controller Mounting Bracket 1
T15064 Eight Position Pluggable Connector 1
T15065 Parts Bag 1
T15066 25’ Extension Cord 1
T15068 Installation & Operation Manual 1
