Code 3 RLS 3999 - Page 22

22
Push Button Switch Control Head, Parts List
Ref No. Description Part No. Qty.
1 8 - 32 x 1/4" Machine Screw T01385 2
2 Knob, Rectangular T01917 1
3 4 - 40 x 3/8", Pan Hd Phil, Black Oxide T06937 7
4 Switch Actuator Keypad, 1x6, Silicone Rubber T10878 1
5 Enclosure, Control Head, RLS Siren T10880 1
6 Standoff, 4 - 40 x .75" T10890 2
7 Label, Faceplate, Model 3998 T10901 1
8 Label, Faceplate, Model 3999 T10902 1
9 Label, Configuration (Part of Wiring Label) T10904 1
1 0 1/4 - 20 x .375", Hex Washer Hd, Zinc T10912 2
11 Switch Actuator, Small Arc, RLS Sirens T10913 2
12 Switch Actuator, Large Arc, RLS Sirens T10914 2
13 Switch Actuator, Oval, RLS Sirens T10915 3
14 Switch Actuator, Rectangular, RLS Sirens T10916 2
15 Bracket, Control Head, RLS Sirens S71528 2
16 Switch Assembly w/Harness S55229 1
17 E-Tray, Control Head, RLS Sirens S71531 1
18 PCB Assembly, Control Head, 1
Model 3998 S71552
Models 3997 & 3999 S71562
