GENEVA OPERATOR MANUAL 9
(4) Remove the impellor disk B by pulling it in
the direction shown.
(5) Remove the whipper seal C and ensure
that the running surface D is smooth and
free of ingredient residues.
(6) Inspect whipper seal for damage and
replace as necessary.
(7) Wash all the removed mixing system
components in destaining fluid and then
rinse thoroughly with clean water.
(8) Reassemble the mixing systems by
following the reverse procedure. Ensure
that whipper seal C is tight against the
running surface before refitting the impellor.
(9) Ensure that both locking pegs E on the mixing system are correctly
located by pressing firmly on the lower part of the mixing system.
(10) When all mixing system components have been refitted, switch on the
machine and perform a flush operation. Check the mixing systems for
leaks and listen for abnormal sounds that may indicate incorrect
assembly.
B
C
D
E
