l To reduce the risk of damage or malfunction due to over-voltage, line noise,
electrostaticdischarge (ESD), power surges, or other irregularities in the
power supply, route all cables and wires away from high-voltage power
sources.
l The I/O module does not contain user-serviceable parts. Do not make any
electrical or mechanical modifications. Unauthorized modifications may void
your warranty.
l Changes or modifications not expressly approved by the party responsible
for regulatory compliance could void the user’s authority to operate the
equipment.
l The maximum torque that can be applied to the terminal block connectors is
0.1921 Nm (1.7 in-lb). Applying torque above thislimit can damage the
connectors.
l Access to the encoder inputs on the In-Sight 5604 Line Scan are not
supported by the I/O module.
l HS COMMON isnot used for high-speed outputs with In-Sight 5000 series
vision systems. The return must use 24V Common.
l When connecting the In-Sight 7000 series vision system to the
CIO-MICROor CIO-MICRO-CC I/O module, the I/O module's I/O port
(DB15) is not supported. Do not connect anything to this port.
l When connecting the In-Sight 7000 series vision system to the
CIO-MICROor CIO-MICRO-CC I/O module, the I/O module's TRIGGER+,
TRIGGER-, HS OUT 0, HS OUT 1 and HS COMMON terminals are not
supported. Do not connect wire leads from remote devices to these
terminals.
l Service loops should be included with all cable connections.
