7
Environmental Temperature Operating: 0°C to 45°C (32°F to 113°F)
Storage: -30°C to 80°C (-22°F to 176°F)
Humidity 90%, non-condensing (Operating and Storage)
Protection IP20 or NEMA 1
Shock 30 G Shock per IEC 68-2-27.
Vibration 2 G from 10-2000 Hz. Vibration per IEC 68-2-6.
Regulatory Compliance CE, FCC, TÜV SÜD NRTL, RoHS
Power Connector Specifi cations
1
2
3
Pin # Signal Name
1 Frame Ground
2 -24VDC (Return)
3 +24VDC (Power)
USB drives should be formatted with a FAT32 fi le system.1.
Refer to the 2. VisionView
®
Software Manual for details on supported touch screens.
