Coinco Vantage - Quick Release Bezel Operation

9
Quick Release
Quick Release
Bezel Operation
Bezel Operation
Push Firmly to
Push Firmly to
Release Bezel
Release Bezel
1. Push firm ly on Q u ick R elea se T abs using a
screw driver tip. Tabs w ill m ove to w ards
bezel and latch.
2. O nce both tabs are latched, the bill
accepto r w ill separate from the bezel.
3. To reattach, push bill a cceptor bod y firm ly
onto be zel until it locks.
