Throttle Cable adjustment
The hand grip throttle free play (2)
should be .078 - .24 in (2-6 mm)
To adjust freeplay
1. Loosen jam nut (3)
2. Turn adjusting nut (4) to proper
setting
3. Once throttle grip is at the proper
freeplay, re-tighten the jam nut (3).
2
3
4
Inadequate throttle play can be
hazardous
The engine speed could rise
when the handlebars are
turned if there is not enough
throttle play. This could result
in loss of control.
Always check throttle play
before each ride. Turn handle-
bars from side to side making
sure throttle does not increase
when doing so.
!
WARNING
MAINTENANCE
Fuel Hose Inspection
Inspect the fuel hose for any cracks or
leaks and make sure all clamps are in
place. Replace the fuel hose if any de-
fects are found.
.078 - .24 in
(2-6 mm)
It is important that the throttle grip
have a certain amount of free play so
the throttle does not rise when the
handlebars are turned from left to
right.
NOTE: After any adjustment, make
sure throttle snaps back to idle when
released.
21
