CC7B3021S CF/CM/CU30B 17.5 800 - 1200 1000 28.0 20.4 14.75 12.50
CC7B3021S CF/CM/CU30C 21 800 - 1200 1000 28.0 20.4 14.75 12.50
CC7B3021S CF/CM/CU30D 24.5 800 - 1200 1000 28.0 20.4 14.75 12.50
CC7B3021S CF/CM/CU36B 17.5 800 - 1200 1000 28.4 21.0 15.50 12.75
CC7B3021S CF/CM/CU36C 21 800 - 1200 1000 28.4 21.0 15.50 12.75
CC7B3021S CF/CM/CU36D 24.5 800 - 1200 1000 28.4 21.0 15.50 12.75
CC7B3021S CF/CM/CU42C 21 800 - 1200 1000 28.8 21.0 15.50 13.00
CC7B3021S CF/CM/CU42D 24.5 800 - 1200 1000 29.0 21.4 15.50 13.00
CC7B3021S CF42B 17.5 800 - 1200 1000 28.8 21.0 15.50 13.00
CC7B3621S CF/CM/CU36B 17.5 1000 - 1400 1200 34.6 25.2 14.50 12.50
CC7B3621S CF/CM/CU36C 21 1000 - 1400 1200 34.6 25.2 14.50 12.50
CC7B3621S CF/CM/CU36D 24.5 1000 - 1400 1200 34.6 25.2 14.50 12.50
CC7B3621S CF/CM/CU42C 21 1000 - 1400 1200 35.4 25.4 15.00 12.50
CC7B3621S CF/CM/CU42D 24.5 1000 - 1400 1200 35.4 26.0 15.00 12.50
CC7B3621S CF/CM/CU48C 21 1000 - 1400 1200 36.0 26.4 15.50 12.75
CC7B3621S CF/CM/CU48D 24.5 1000 - 1400 1200 36.0 26.4 15.50 12.75
CC7B3621S CF/CM/CU60C 21 1000 - 1400 1200 36.0 26.0 15.50 12.75
CC7B3621S CF/CM/CU60D 24.5 1000 - 1400 1200 36.0 26.0 15.50 12.75
CC7B3621S CF42B 17.5 1000 - 1400 1200 35.4 25.4 15.00 12.50
CC7B4221S CF/CM/CU42C 21 1200 - 1600 1400 41.0 29.0 15.00 12.50
CC7B4221S CF/CM/CU42D 24.5 1200 - 1600 1400 41.0 29.0 15.00 12.50
CC7B4221S CF/CM/CU48C 21 1200 - 1600 1400 41.5 29.2 15.50 12.75
CC7B4221S CF/CM/CU48D 24.5 1200 - 1600 1400 41.5 29.2 15.50 12.75
CC7B4221S CF/CM/CU60C 21 1200 - 1600 1400 42.0 30.2 15.50 12.75
CC7B4221S CF/CM/CU60D 24.5 1200 - 1600 1400 42.0 30.2 15.50 12.75
CC7B4221S CF/CM64D 24.5 1200 - 1600 1400 42.0 30.0 15.75 13.00
CC7B4821S CF/CM/CU48C 21 1400 - 1800 1500 45.0 32.0 14.75 12.25
CC7B4821S CF/CM/CU48D 24.5 1400 - 1800 1500 45.0 32.0 14.75 12.25
CC7B4821S CF/CM/CU60C 21 1400 - 1800 1500 45.5 33.0 15.50 12.75
CC7B4821S CF/CM/CU60D 24.5 1400 - 1800 1500 46.0 33.4 15.50 12.75
CC7B4821S CF/CM64D 24.5 1400 - 1800 1500 47.0 34.0 15.50 13.00
CC7B6021S CF/CM/CU60C 21 1520 - 1920 1725 56.5 40.5 14.50 12.00
CC7B6021S CF/CM/CU60D 24.5 1520 - 1920 1725 56.5 40.5 14.50 12.00
CC7B6021S CF/CM64D 24.5 1520 - 1920 1725 57.5 40.5 15.10 12.75
For rated condition information, see the footnotes below the System Capacity - Single Piece and Modular Air Handlers table.
1. Requires a S1-2FD06700224 Blower Time Delay unless a standard furnace is equipped with one.
COOLING CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils (Coil Only Ratings) (Continued)
UNIT MODEL
COIL
CFM RANGE
(MIN.-MAX.)
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER
1
EER
TOTAL SENS.
