Coleman CC7B18 - Page 38

5495505-CTG-A-0418
38 Johnson Controls Unitary Products
PSC furnaces, such as the TG8S, TGLS, and TG9S, use Coil Only Ratings.
CC7B6021S TPLC100C16MP13C 21.0 CF/CM/CU60C 1700 56.0 42.0 14.25 12.20
CC7B6021S TPLC100C16MP13C 21.0 CF/CM/CU60D 1700 56.5 42.5 14.50 12.25
CC7B6021S TPLC100C20MP13C 21.0 CF/CM/CU60C 1550 56.0 40.5 15.00 12.50
CC7B6021S TPLC100C20MP13C 21.0 CF/CM/CU60D 1550 56.0 40.5 15.25 12.75
CC7B6021S TPLC100C20MP13C 21.0 CF/CM64D 1550 57.0 41.0 15.50 12.75
CC7B6021S TPLC120C20MP13C 21.0 CF/CM/CU60C 1550 56.0 40.5 15.00 12.50
CC7B6021S TPLC120C20MP13C 21.0 CF/CM/CU60D 1550 56.0 40.5 15.25 12.75
CC7B6021S TPLC120C20MP13C 21.0 CF/CM64D 1550 57.0 41.0 15.50 12.75
CC7B6021S CP9C100C16MP13C 21.0 CF/CM/CU60C 1600 56.0 41.0 14.75 12.25
CC7B6021S CP9C100C16MP13C 21.0 CF/CM/CU60D 1600 56.0 41.0 15.00 12.50
CC7B6021S CP9C100C16MP13C 21.0 CF/CM64D 1600 57.0 41.5 15.00 12.50
CC7B6021S CP9C100C20MP13C 21.0 CF/CM/CU60C 1600 56.0 41.0 14.75 12.25
CC7B6021S CP9C100C20MP13C 21.0 CF/CM64D 1600 57.0 41.5 15.00 12.50
CC7B6021S CP9C120D20MP13C 24.5 CF/CM/CU60D 1575 56.5 41.0 15.25 12.75
CC7B6021S CP9C120D20MP13C 24.5 CF/CM64D 1575 57.0 41.0 15.50 12.75
CC7B6021S CPLC080C16MP13C 21.0 CF/CM/CU60C 1700 56.0 42.0 14.25 12.20
CC7B6021S CPLC080C16MP13C 21.0 CF/CM/CU60D 1700 56.5 42.5 14.50 12.25
CC7B6021S CPLC100C16MP13C 21.0 CF/CM/CU60C 1700 56.0 42.0 14.25 12.20
CC7B6021S CPLC100C16MP13C 21.0 CF/CM/CU60D 1700 56.5 42.5 14.50 12.25
CC7B6021S CPLC100C20MP13C 21.0 CF/CM/CU60C 1550 56.0 40.5 15.00 12.50
CC7B6021S CPLC100C20MP13C 21.0 CF/CM/CU60D 1550 56.0 40.5 15.25 12.75
CC7B6021S CPLC100C20MP13C 21.0 CF/CM64D 1550 57.0 41.0 15.50 12.75
CC7B6021S CPLC120C20MP13C 21.0 CF/CM/CU60C 1550 56.0 40.5 15.00 12.50
CC7B6021S CPLC120C20MP13C 21.0 CF/CM/CU60D 1550 56.0 40.5 15.25 12.75
CC7B6021S CPLC120C20MP13C 21.0 CF/CM64D 1550 57.0 41.0 15.50 12.75
For rated condition information, see the footnotes below the System Capacity - Single Piece and Modular Air Handlers table.
1. High Efficiency Motor Furnaces have B.O.D (Blower Off Delay) standard.
2. CM coils available with a factory installed horizontal drain pan. See price pages for specific model number.
COOLING CAPACITY - With High Efficiency Motor Furnaces
1
(Continued)
UNIT
MODEL
FURNACE
COIL
MODEL
2
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.
