Coleman CC7B18 - Page 51

5495505-CTG-A-0418
Johnson Controls Unitary Products 51
COIL MULTIPLIERS- 2.5 TON
Air Handler Coil T.C. S.C. KW
– CF/CM/CU30B 0.99 0.97 1.01
– CF/CM/CU30C 0.99 0.97 1.01
– CF/CM/CU30D 0.99 0.97 1.01
– CF/CM/CU36B 1.00 1.00 1.00
– CF/CM/CU36C 1.00 1.00 1.00
– CF/CM/CU36D 1.00 1.00 1.00
– CF42B 1.01 1.00 0.99
– CF/CM/CU42C 1.01 1.00 0.99
– CF/CM/CU42D 1.02 1.02 1.00
AE30BX21 – 0.98 0.92 0.89
AE36BX21 – 1.03 1.03 0.92
AE36CX21 – 1.03 1.04 0.90
AP30BX21 – 0.99 1.00 0.99
AP36BX21 – 1.01 1.01 0.99
AP36CX21 – 1.02 1.00 1.00
AVC30BX21 – 0.97 0.91 0.90
AVC36BX21 – 1.03 1.05 0.92
AVC36CX21 – 1.02 1.01 0.90
ME08BN21 CF/CM30B 0.99 0.96 0.90
ME08BN21 CF/CM36B 1.01 0.98 0.91
ME08BN21 CF42B 1.02 0.96 0.91
ME12BN21 CF/CM30B 0.98 0.91 0.89
ME12BN21 CF/CM36B 1.00 0.94 0.89
ME12BN21 CF42B 1.04 1.02 0.93
ME14DN21 CF/CM30D 1.02 1.03 0.88
ME14DN21 CF/CM36D 1.04 1.07 0.90
ME14DN21 CF/CM42D 1.05 1.05 0.91
ME16CN21 CF/CM30C 1.01 1.03 0.94
ME16CN21 CF/CM36C 1.04 1.06 0.93
ME16CN21 CF/CM42C 1.05 1.08 0.94
MVC08BN21 CF/CM30B 0.99 0.96 0.93
MVC08BN21 CF/CM36B 1.01 1.02 0.95
MVC08BN21 CF42B 1.01 1.01 0.94
MVC12BN21 CF/CM30B 0.99 0.94 0.90
MVC12BN21 CF/CM36B 0.98 0.95 0.92
MVC12BN21 CF42B 1.00 0.95 0.91
MVC14DN21 CF/CM30D 1.00 0.99 0.91
MVC14DN21 CF/CM36D 1.02 1.03 0.90
MVC14DN21 CF/CM42D 1.04 1.05 0.89
MVC16CN21 CF/CM30C 0.99 0.97 0.92
MVC16CN21 CF/CM36C 1.01 1.02 0.92
MVC16CN21 CF/CM42C 1.02 1.01 0.91
MVC20DN21 CF/CM42D 1.04 1.06 0.93
FURNACE MULTIPLIERS- 2.5 TON
Furnaces Coil T.C. S.C. KW
TM8V060A12MP12C CF/CM/CU30A 0.97 1.01 0.95
TM8V060A12MP12C CF/CM36A 1.01 1.09 0.96
TM8V080B12MP12C CF/CM/CU30B 0.98 1.03 0.94
TM8V080B12MP12C CF/CM/CU36B 0.98 1.03 0.92
TM8V080B12MP12C CF42B 0.99 1.02 0.92
TM8V080C16MP12C CF/CM/CU30C 1.00 1.07 0.93
TM8V080C16MP12C CF/CM/CU30D 1.00 1.07 0.91
TM8V080C16MP12C CF/CM/CU36C 1.02 1.14 0.93
TM8V080C16MP12C CF/CM/CU36D 1.02 1.14 0.91
TM8V080C16MP12C CF/CM/CU42C 1.04 1.14 0.93
TM8V080C16MP12C CF/CM/CU42D 1.04 1.14 0.93
TM8V100C16MP12C CF/CM/CU30C 1.00 1.07 0.93
TM8V100C16MP12C CF/CM/CU30D 1.00 1.07 0.91
TM8V100C16MP12C CF/CM/CU36C 1.02 1.14 0.93
TM8V100C16MP12C CF/CM/CU36D 1.02 1.14 0.91
TM8V100C16MP12C CF/CM/CU42C 1.04 1.14 0.93
TM8V100C16MP12C CF/CM/CU42D 1.04 1.14 0.93
TM8X060A12MP11 CF/CM/CU30A 0.96 1.00 0.91
TM8X060A12MP11 CF/CM36A 0.97 1.02 0.92
TM8X080B12MP11 CF/CM/CU30B 1.00 1.07 0.94
TM8X080B12MP11 CF/CM/CU36B 1.02 1.10 0.93
TM8X080B12MP11 CF42B 1.01 1.06 0.91
TM8X080C16MP11 CF/CM/CU30C 1.00 1.07 0.91
TM8X080C16MP11 CF/CM/CU30D 1.02 1.09 0.91
TM8X080C16MP11 CF/CM/CU36C 1.01 1.08 0.90
TM8X080C16MP11 CF/CM/CU36D 1.03 1.10 0.92
TM8X080C16MP11 CF/CM/CU42C 1.02 1.07 0.90
TM8X080C16MP11 CF/CM/CU42D 1.04 1.10 0.91
TM8X100C16MP11 CF/CM/CU30C 1.00 1.07 0.91
TM8X100C16MP11 CF/CM/CU30D 1.02 1.09 0.91
TM8X100C16MP11 CF/CM/CU36C 1.01 1.08 0.90
TM8X100C16MP11 CF/CM/CU36D 1.03 1.10 0.92
TM8X100C16MP11 CF/CM/CU42C 1.02 1.07 0.90
TM8X100C16MP11 CF/CM/CU42D 1.04 1.10 0.91
TM8X100C20MP11 CF/CM/CU30C 1.02 1.09 0.91
TM8X100C20MP11 CF/CM/CU30D 1.02 1.09 0.91
TM8X100C20MP11 CF/CM/CU36C 1.03 1.11 0.92
TM8X100C20MP11 CF/CM/CU36D 1.03 1.11 0.89
TM8X100C20MP11 CF/CM/CU42C 1.04 1.11 0.91
TM8X100C20MP11 CF/CM/CU42D 1.04 1.11 0.89
TM8X120C20MP11 CF/CM/CU30C 1.02 1.09 0.91
TM8X120C20MP11 CF/CM/CU30D 1.02 1.09 0.91
TM8X120C20MP11 CF/CM/CU36C 1.03 1.11 0.92
TM8X120C20MP11 CF/CM/CU36D 1.03 1.11 0.89
TM8X120C20MP11 CF/CM/CU42C 1.04 1.11 0.91
TM8X120C20MP11 CF/CM/CU42D 1.04 1.11 0.89
TM8Y060A12MP11 CF/CM/CU30A 0.96 1.00 0.91
TM8Y060A12MP11 CF/CM36A 0.97 1.02 0.92
TM8Y080B12MP11 CF/CM/CU30B 1.00 1.07 0.94
TM8Y080B12MP11 CF/CM/CU36B 1.02 1.10 0.93
TM8Y080B12MP11 CF42B 1.01 1.06 0.91
TM8Y080C16MP11 CF/CM/CU30C 1.00 1.07 0.91
TM8Y080C16MP11 CF/CM/CU30D 1.02 1.09 0.91
TM8Y080C16MP11 CF/CM/CU36C 1.01 1.08 0.90
TM8Y080C16MP11 CF/CM/CU36D 1.03 1.10 0.92
