Coleman CC7B18 - Page 55

5495505-CTG-A-0418
Johnson Controls Unitary Products 55
COIL MULTIPLIERS- 3 TON
Air Handler Coil T.C. S.C. KW
– CF/CM/CU36B 0.96 0.96 0.98
– CF/CM/CU36C 0.96 0.96 0.98
– CF/CM/CU36D 0.96 0.96 0.98
– CF42B 0.98 0.96 1.00
– CF/CM/CU42C 0.98 0.96 1.00
– CF/CM/CU42D 0.98 0.99 1.00
– CF/CM/CU48C 1.00 1.00 1.00
– CF/CM/CU48D 1.00 1.00 1.00
– CF/CM/CU60C 1.00 0.99 1.00
– CF/CM/CU60D 1.00 0.99 1.00
AE36BX21 – 0.96 0.91 0.91
AE36CX21 – 0.96 0.91 0.88
AE42CX21 – 0.98 0.93 0.90
AE48CX21 – 1.00 1.03 0.91
AE48DX21 – 1.00 1.02 0.89
AE60CX21 – 1.00 1.04 0.94
AP36BX21 – 0.96 0.91 0.98
AP36CX21 – 0.96 0.90 0.96
AP42CX21 – 0.98 0.95 1.00
AP48CX21 – 1.00 0.99 1.00
AP48DX21 – 1.00 0.99 1.00
AP60CX21 – 1.00 1.03 1.04
AP60DX21 – 1.00 0.99 1.05
AVC36BX21 – 0.96 0.90 0.89
AVC36CX21 – 0.96 0.90 0.88
AVC42CX21 – 0.98 0.97 0.90
AVC48CX21 – 1.00 0.97 0.91
AVC48DX21 – 1.00 0.99 0.89
AVC60CX21 – 1.00 0.98 0.89
ME12BN21 CF/CM36B 0.96 0.91 0.89
ME12BN21 CF42B 0.98 0.92 0.93
ME14DN21 CF/CM36D 0.96 1.00 0.88
ME14DN21 CF/CM42D 0.98 0.99 0.88
ME14DN21 CF/CM48D 1.00 1.01 0.89
ME14DN21 CF/CM60D 1.00 0.96 0.88
ME16CN21 CF/CM36C 0.96 0.99 0.88
ME16CN21 CF/CM42C 0.98 0.99 0.88
ME16CN21 CF/CM48C 1.00 1.02 0.89
ME16CN21 CF/CM60C 1.00 1.02 0.89
ME20DN21 CF/CM36D 0.98 1.03 0.95
ME20DN21 CF/CM42D 1.00 1.03 0.94
ME20DN21 CF/CM48D 1.00 1.04 0.93
ME20DN21 CF/CM60D 1.00 1.03 0.93
MVC08BN21 CF/CM36B 1.00 0.96 0.96
MVC12BN21 CF/CM36B 1.00 0.95 0.96
MVC12BN21 CF42B 1.00 0.95 0.96
MVC14DN21 CF/CM36D 1.00 1.00 0.93
MVC14DN21 CF/CM42D 1.00 0.98 0.91
MVC14DN21 CF/CM48D 1.00 0.99 0.91
MVC14DN21 CF/CM60D 1.00 0.96 0.91
MVC16CN21 CF/CM36C 1.00 0.99 0.94
MVC16CN21 CF/CM42C 1.00 0.95 0.93
MVC16CN21 CF/CM48C 1.00 0.97 0.91
MVC16CN21 CF/CM60C 1.00 1.00 0.91
MVC20DN21 CF/CM36D 1.00 1.00 0.91
MVC20DN21 CF/CM42D 1.00 1.00 0.93
MVC20DN21 CF/CM48D 1.00 0.99 0.91
MVC20DN21 CF/CM60D 1.00 1.01 0.89
FURNACE MULTIPLIERS- 3 TON
Furnaces Coil T.C. S.C. KW
TM8V080C16MP12C CF/CM/CU36C 0.96 1.01 0.91
TM8V080C16MP12C CF/CM/CU36D 1.00 1.05 0.93
TM8V080C16MP12C CF/CM/CU42C 1.00 1.05 0.94
TM8V080C16MP12C CF/CM/CU42D 1.00 1.05 0.93
TM8V080C16MP12C CF/CM/CU48C 1.00 1.04 0.93
TM8V080C16MP12C CF/CM/CU48D 1.00 1.04 0.93
TM8V080C16MP12C CF/CM/CU60C 1.00 1.05 0.93
TM8V080C16MP12C CF/CM/CU60D 1.00 1.05 0.91
TM8V100C16MP12C CF/CM/CU36C 0.96 1.01 0.91
TM8V100C16MP12C CF/CM/CU36D 1.00 1.05 0.93
TM8V100C16MP12C CF/CM/CU42C 1.00 1.05 0.94
TM8V100C16MP12C CF/CM/CU42D 1.00 1.05 0.93
TM8V100C16MP12C CF/CM/CU48C 1.00 1.04 0.93
TM8V100C16MP12C CF/CM/CU48D 1.00 1.04 0.93
TM8V100C16MP12C CF/CM/CU60C 1.00 1.05 0.93
TM8V100C16MP12C CF/CM/CU60D 1.00 1.05 0.91
TM8V100C20MP12C CF/CM/CU36C 0.97 1.02 0.91
TM8V100C20MP12C CF/CM/CU36D 1.00 1.05 0.91
TM8V100C20MP12C CF/CM/CU42C 1.00 1.05 0.94
TM8V100C20MP12C CF/CM/CU42D 1.00 1.05 0.91
TM8V100C20MP12C CF/CM/CU48C 1.00 1.04 0.93
TM8V100C20MP12C CF/CM/CU48D 1.00 1.07 0.89
TM8V100C20MP12C CF/CM/CU60C 1.00 1.05 0.93
TM8V100C20MP12C CF/CM/CU60D 1.00 1.05 0.91
TM8V120C20MP12C CF/CM/CU36C 0.97 1.02 0.91
TM8V120C20MP12C CF/CM/CU36D 1.00 1.05 0.91
TM8V120C20MP12C CF/CM/CU42C 1.00 1.05 0.94
TM8V120C20MP12C CF/CM/CU42D 1.00 1.05 0.91
TM8V120C20MP12C CF/CM/CU48C 1.00 1.04 0.93
TM8V120C20MP12C CF/CM/CU48D 1.00 1.07 0.89
TM8V120C20MP12C CF/CM/CU60C 1.00 1.05 0.93
TM8V120C20MP12C CF/CM/CU60D 1.00 1.05 0.91
TM8X060A12MP11 CF/CM36A 0.96 0.99 0.96
TM8X080B12MP11 CF/CM/CU36B 0.98 1.04 0.92
TM8X080B12MP11 CF42B 0.99 1.03 0.95
TM8X080C16MP11 CF/CM/CU36C 0.96 1.01 0.89
TM8X080C16MP11 CF/CM/CU36D 0.97 1.03 0.90
TM8X080C16MP11 CF/CM/CU42C 0.98 1.02 0.91
TM8X080C16MP11 CF/CM/CU42D 0.99 1.03 0.91
TM8X080C16MP11 CF/CM/CU48C 1.00 1.04 0.91
TM8X080C16MP11 CF/CM/CU48D 1.00 1.04 0.91
TM8X080C16MP11 CF/CM/CU60C 1.00 1.03 0.91
TM8X080C16MP11 CF/CM/CU60D 1.00 1.04 0.91
TM8X100C16MP11 CF/CM/CU36C 0.96 1.01 0.89
TM8X100C16MP11 CF/CM/CU36D 0.97 1.03 0.90
TM8X100C16MP11 CF/CM/CU42C 0.98 1.02 0.91
TM8X100C16MP11 CF/CM/CU42D 0.99 1.03 0.91
TM8X100C16MP11 CF/CM/CU48C 1.00 1.04 0.91
TM8X100C16MP11 CF/CM/CU48D 1.00 1.04 0.91
TM8X100C16MP11 CF/CM/CU60C 1.00 1.03 0.91
COIL MULTIPLIERS- 3 TON
Air Handler Coil T.C. S.C. KW
