COIL MULTIPLIERS- 3.5 TON
Air Handler Coil T.C. S.C. KW
– CF/CM/CU42C 0.99 0.99 1.01
– CF/CM/CU42D 0.99 0.99 1.01
– CF/CM/CU48C 1.00 1.00 1.00
– CF/CM/CU48D 1.00 1.00 1.00
– CF/CM/CU60C 1.01 1.03 1.01
– CF/CM/CU60D 1.01 1.03 1.01
– CF/CM64D 1.01 1.03 0.99
AE42CX21 – 1.00 0.95 0.93
AE48CX21 – 1.01 0.97 0.91
AE48DX21 – 1.01 0.98 0.91
AE60CX21 – 1.01 1.05 0.92
AE60DX21 – 1.01 1.03 0.91
AP42CX21 – 0.98 0.93 1.00
AP48CX21 – 1.00 0.98 1.00
AP48DX21 – 1.01 1.00 0.99
AP60CX21 – 1.01 1.03 1.03
AP60DX21 – 1.01 1.03 1.03
AVC42CX21 – 1.00 0.95 0.93
AVC48CX21 – 1.01 0.97 0.92
AVC48DX21 – 1.01 0.98 0.91
AVC60CX21 – 1.01 1.01 0.92
AVC60DX21 – 1.01 0.97 0.91
ME14DN21 CF/CM42D 0.99 0.95 0.90
ME14DN21 CF/CM48D 1.00 0.94 0.91
ME14DN21 CF/CM60D 1.01 0.99 0.89
ME14DN21 CF/CM64D 1.01 0.96 0.91
ME16CN21 CF/CM42C 0.98 0.93 0.90
ME16CN21 CF/CM48C 1.01 0.98 0.91
ME16CN21 CF/CM60C 1.01 0.99 0.91
ME20DN21 CF/CM42D 1.00 1.03 0.93
ME20DN21 CF/CM48D 1.01 1.05 0.91
ME20DN21 CF/CM60D 1.01 1.05 0.91
ME20DN21 CF/CM64D 1.01 1.04 0.91
MVC12BN21 CF42B 0.98 0.97 0.96
MVC14DN21 CF/CM42D 1.00 1.00 0.91
MVC14DN21 CF/CM48D 1.00 0.99 0.91
MVC14DN21 CF/CM60D 1.00 0.96 0.91
MVC14DN21 CF/CM64D 1.01 0.96 0.91
MVC16CN21 CF/CM42C 0.99 0.99 0.93
MVC16CN21 CF/CM48C 1.01 1.01 0.92
MVC16CN21 CF/CM60C 1.01 1.01 0.92
MVC20DN21 CF/CM42D 1.00 0.98 0.91
MVC20DN21 CF/CM48D 1.01 0.99 0.92
MVC20DN21 CF/CM60D 1.01 1.01 0.91
MVC20DN21 CF/CM64D 1.01 1.01 0.92
FURNACE MULTIPLIERS- 3.5 TON
Furnaces Coil T.C. S.C. KW
TM8V080C16MP12C CF/CM/CU42C 1.00 1.11 0.98
TM8V080C16MP12C CF/CM/CU42D 1.01 1.12 0.92
TM8V080C16MP12C CF/CM/CU48C 1.01 1.12 0.96
TM8V080C16MP12C CF/CM/CU48D 1.01 1.12 0.94
TM8V080C16MP12C CF/CM/CU60C 1.01 1.13 0.94
TM8V080C16MP12C CF/CM/CU60D 1.01 1.13 0.94
TM8V080C16MP12C CF/CM64D 1.01 1.13 0.94
TM8V100C16MP12C CF/CM/CU42C 1.00 1.11 0.98
TM8V100C16MP12C CF/CM/CU42D 1.01 1.12 0.92
TM8V100C16MP12C CF/CM/CU48C 1.01 1.12 0.96
TM8V100C16MP12C CF/CM/CU48D 1.01 1.12 0.94
TM8V100C16MP12C CF/CM/CU60C 1.01 1.13 0.94
TM8V100C16MP12C CF/CM/CU60D 1.01 1.13 0.94
TM8V100C16MP12C CF/CM64D 1.01 1.13 0.94
TM8V100C20MP12C CF/CM/CU42C 1.00 1.11 0.96
TM8V100C20MP12C CF/CM/CU42D 1.01 1.12 0.91
TM8V100C20MP12C CF/CM/CU48C 1.01 1.12 0.94
TM8V100C20MP12C CF/CM/CU48D 1.01 1.12 0.94
TM8V100C20MP12C CF/CM/CU60C 1.01 1.13 0.94
TM8V100C20MP12C CF/CM/CU60D 1.01 1.13 0.94
TM8V100C20MP12C CF/CM64D 1.01 1.13 0.92
TM8V120C20MP12C CF/CM/CU42C 1.00 1.11 0.96
TM8V120C20MP12C CF/CM/CU42D 1.01 1.12 0.91
TM8V120C20MP12C CF/CM/CU48C 1.01 1.12 0.94
TM8V120C20MP12C CF/CM/CU48D 1.01 1.12 0.94
TM8V120C20MP12C CF/CM/CU60C 1.01 1.13 0.94
TM8V120C20MP12C CF/CM/CU60D 1.01 1.13 0.94
TM8V120C20MP12C CF/CM64D 1.01 1.13 0.92
TM8X080B12MP11 CF42B 0.95 0.98 0.93
TM8X080C16MP11 CF/CM/CU42C 1.00 1.11 0.96
TM8X080C16MP11 CF/CM/CU42D 1.00 1.12 0.94
TM8X080C16MP11 CF/CM/CU48C 1.01 1.12 0.96
TM8X080C16MP11 CF/CM/CU48D 1.01 1.13 0.96
TM8X080C16MP11 CF/CM/CU60C 1.01 1.13 0.94
TM8X080C16MP11 CF/CM/CU60D 1.01 1.14 0.92
TM8X080C16MP11 CF/CM64D 1.01 1.13 0.94
TM8X100C16MP11 CF/CM/CU42C 1.00 1.11 0.96
TM8X100C16MP11 CF/CM/CU42D 1.00 1.12 0.94
TM8X100C16MP11 CF/CM/CU48C 1.01 1.12 0.96
TM8X100C16MP11 CF/CM/CU48D 1.01 1.13 0.96
TM8X100C16MP11 CF/CM/CU60C 1.01 1.13 0.94
TM8X100C16MP11 CF/CM/CU60D 1.01 1.14 0.92
TM8X100C16MP11 CF/CM64D 1.01 1.13 0.94
TM8X100C20MP11 CF/CM/CU42C 1.00 1.12 0.94
TM8X100C20MP11 CF/CM/CU42D 0.99 1.05 0.93
TM8X100C20MP11 CF/CM/CU48C 1.01 1.13 0.92
TM8X100C20MP11 CF/CM/CU48D 1.01 1.15 0.92
TM8X100C20MP11 CF/CM/CU60C 1.01 1.14 0.92
TM8X100C20MP11 CF/CM/CU60D 1.01 1.15 0.92
TM8X100C20MP11 CF/CM64D 1.01 1.13 0.91
TM8X120C20MP11 CF/CM/CU42C 1.00 1.12 0.94
TM8X120C20MP11 CF/CM/CU42D 0.99 1.05 0.93
TM8X120C20MP11 CF/CM/CU48C 1.01 1.13 0.92
TM8X120C20MP11 CF/CM/CU48D 1.01 1.15 0.92
TM8X120C20MP11 CF/CM/CU60C 1.01 1.14 0.92
TM8X120C20MP11 CF/CM/CU60D 1.01 1.15 0.92
TM8X120C20MP11 CF/CM64D 1.01 1.13 0.91
TM8Y080B12MP11 CF42B 0.95 0.98 0.93
TM8Y080C16MP11 CF/CM/CU42C 1.00 1.11 0.96
TM8Y080C16MP11 CF/CM/CU42D 1.00 1.12 0.94
TM8Y080C16MP11 CF/CM/CU48C 1.01 1.12 0.96
TM8Y080C16MP11 CF/CM/CU48D 1.01 1.13 0.96
TM8Y080C16MP11 CF/CM/CU60C 1.01 1.13 0.94
TM8Y080C16MP11 CF/CM/CU60D 1.01 1.14 0.92
TM8Y080C16MP11 CF/CM64D 1.01 1.13 0.94
TM8Y100C16MP11 CF/CM/CU42C 1.00 1.11 0.96
FURNACE MULTIPLIERS- 3.5 TON (Continued)
Furnaces Coil T.C. S.C. KW
