5495505-CTG-A-0418
68 Johnson Controls Unitary Products
COIL MULTIPLIERS- 5 TON
Air Handler Coil T.C. S.C. KW
– CF/CM/CU60C 0.98 1.00 1.04
– CF/CM/CU60D 0.98 1.00 1.04
– CF/CM64D 1.00 1.00 1.00
AE60CX21 – 0.97 0.97 0.99
AE60DX21 – 1.01 1.01 1.01
AP60CX21 – 0.97 0.94 1.05
AP60DX21 – 0.97 0.97 1.03
AVC60CX21 – 0.98 0.99 1.02
AVC60DX21 – 1.01 1.00 0.99
ME16CN21 CF/CM60C 0.99 1.02 0.99
ME20DN21 CF/CM60D 0.98 0.97 0.98
ME20DN21 CF/CM64D 1.01 0.99 0.99
MVC16CN21 CF/CM60C 0.97 0.97 0.99
MVC20DN21 CF/CM60D 0.98 0.98 0.98
MVC20DN21 CF/CM64D 0.99 0.99 0.97
FURNACE MULTIPLIERS- 5 TON
Furnaces Coil T.C. S.C. KW
TM8V080C16MP12C CF/CM/CU60C 0.97 1.04 1.02
TM8V080C16MP12C CF/CM/CU60D 0.98 1.04 1.02
TM8V100C16MP12C CF/CM/CU60C 0.97 1.04 1.02
TM8V100C16MP12C CF/CM/CU60D 0.98 1.04 1.02
TM8V100C20MP12C CF/CM/CU60C 0.97 1.00 0.99
TM8V100C20MP12C CF/CM/CU60D 0.97 1.00 0.97
TM8V100C20MP12C CF/CM64D 0.99 1.01 0.99
TM8V120C20MP12C CF/CM/CU60C 0.97 1.00 0.99
TM8V120C20MP12C CF/CM/CU60D 0.97 1.00 0.97
TM8V120C20MP12C CF/CM64D 0.99 1.01 0.99
TM8X080C16MP11 CF/CM/CU60C 0.97 0.99 1.00
TM8X080C16MP11 CF/CM/CU60D 0.97 1.00 1.01
TM8X080C16MP11 CF/CM64D 0.98 1.00 1.00
TM8X100C16MP11 CF/CM/CU60C 0.97 0.99 1.00
TM8X100C16MP11 CF/CM/CU60D 0.97 1.00 1.01
TM8X100C16MP11 CF/CM64D 0.98 1.00 1.00
TM8X100C20MP11 CF/CM/CU60C 0.97 1.00 0.99
TM8X100C20MP11 CF/CM/CU60D 0.98 1.02 0.98
TM8X100C20MP11 CF/CM64D 0.99 1.01 0.99
TM8X120C20MP11 CF/CM/CU60C 0.97 1.00 0.99
TM8X120C20MP11 CF/CM/CU60D 0.98 1.02 0.98
TM8X120C20MP11 CF/CM64D 0.99 1.01 0.99
TM8Y080C16MP11 CF/CM/CU60C 0.97 0.99 1.00
TM8Y080C16MP11 CF/CM/CU60D 0.97 1.00 1.01
TM8Y080C16MP11 CF/CM64D 0.98 1.00 1.00
TM8Y100C16MP11 CF/CM/CU60C 0.97 0.99 1.00
TM8Y100C16MP11 CF/CM/CU60D 0.97 1.00 1.01
TM8Y100C16MP11 CF/CM64D 0.98 1.00 1.00
TM8Y100C20MP11 CF/CM/CU60C 0.97 1.00 0.99
TM8Y100C20MP11 CF/CM/CU60D 0.98 1.02 0.98
TM8Y100C20MP11 CF/CM64D 0.99 1.01 0.99
TM8Y120C20MP11 CF/CM/CU60C 0.97 1.00 0.99
TM8Y120C20MP11 CF/CM/CU60D 0.98 1.02 0.98
TM8Y120C20MP11 CF/CM64D 0.99 1.01 0.99
TM9E100C20MP11 CF/CM/CU60C 0.97 0.99 1.00
TM9E100C20MP11 CF/CM/CU60D 0.97 1.00 0.99
TM9E100C20MP11 CF/CM64D 0.99 1.01 1.01
TM9E120D20MP11 CF/CM/CU60D 0.98 1.02 1.00
TM9E120D20MP11 CF/CM64D 0.99 1.02 0.99
TM9V100C16MP12C CF/CM/CU60C 0.97 1.01 1.01
TM9V100C16MP12C CF/CM/CU60D 0.97 1.01 0.99
TM9V100C16MP12C CF/CM64D 0.99 1.02 1.01
TM9V100C20MP12C CF/CM/CU60C 0.97 1.01 1.01
TM9V100C20MP12C CF/CM64D 0.99 1.02 1.01
TM9V120D20MP12C CF/CM/CU60D 0.98 1.02 0.98
TM9V120D20MP12C CF/CM64D 0.99 1.02 0.99
TM9Y100C20MP11 CF/CM/CU60C 0.97 0.99 1.00
TM9Y100C20MP11 CF/CM/CU60D 0.97 1.00 0.99
TM9Y100C20MP11 CF/CM64D 0.99 1.01 1.01
TM9Y120D20MP11 CF/CM/CU60D 0.98 1.02 1.00
TM9Y120D20MP11 CF/CM64D 0.99 1.02 0.99
TMLV080C16MP12C CF/CM/CU60C 0.97 1.04 1.02
TMLV080C16MP12C CF/CM/CU60D 0.98 1.04 1.02
TMLV100C16MP12C CF/CM/CU60C 0.97 1.04 1.02
