11
c. Assemble the back of the left and right
tracks (CL and CM) to the upper back
panel (CN), as shown in image C.
Close up, upper back panel (CN)
connection
7
C
ASSEMBLY INSTRUCTIONS
CN
CM
CL
YOU WILL NEED:
7 10 11
X 2 X 2 X 2
Back view
a. Assemble the left and right tracks
(CL and CM) for the grease tray,
as shown in images A to C.
b. Insert the left and right tracks (CL
and CM) into the two clips located
on the top of the front brace (CG),
as shown in figure B.
F
A
Close up, front brace (CG) connection
B
CM
CM
CG
CL
To Next Page
