ASSEMBLY INSTRUCTIONS
1
a. Separate the 2 dierent types of
castors: 2 locking castors (ED) and 2
regular castors (EE).
NOTE: Regular castors (EE) need to
be assembled to the front of
the bottom shelf (EC), and
locking castors (ED) need to be
assembled to the back of the
bottom shelf (EC), as shown in
image A.
b. Insert the U Pin (#13) into one of
the regular castors (EE), as shown in
image B. Attach the regular castor
(EE) to the front of the bottom shelf
(EC), and use the U Pin (#13) to secure
and tighten.
Repeat for remaining 3 castors
(ED & EE).
YOU WILL NEED:
6
13
X 1
Upside down view
EE
EE
EC
ED
ED
EE
13
Close up
B
A
