AIR FLOW DATA
HIGH / LOW SPEED COOLING AND HEAT PUMP CFM
TM(8,L)V060A12MP11C TM(8,L)V080B12MP11C Jumper Settings
High Low High Low COOL Tap ADJ Tap*
1309 851 1331 865 A B
1108 720 1090 708 B B
1190 774 1210 786 A A
1007 655 991 644 B A
1071 696 1089 708 A C
901 586 891 579 C B
906 589 892 580 B C
686 446 636 413 D B
819 532 810 526 C A
624 406 578 410 D A
737 479 729 474 C C
553 403 520 410 D C
TM(8,L)V080C16MP11C TM(8,L)V100C16MP11C Jumper Settings
High Low High Low COOL Tap ADJ Tap*
1794 1166 1765 1147 A B
1570 1020 1568 1019 B B
1631 1060 1605 1043 A A
1427 928 1425 926 B A
1468 954 1444 939 A C
1351 878 1331 865 C B
1284 835 1282 833 B C
1115 725 1086 706 D B
1228 798 1210 786 C A
1014 659 987 642 D A
1105 718 1089 708 C C
913 593 888 577 D C
TM(8,L)V100C20MP11C TM(8,L)V120C20MP11C Jumper Settings
High Low High Low COOL Tap ADJ Tap*
2230 1450 2200 1430 A B
1792 1165 1826 1187 B B
2030 1320 2065 1342 A A
1629 1059 1660 1079 B A
1827 1188 1858 1208 A C
1584 1030 1642 1067 C B
1466 953 1494 971 B C
1382 898 1401 911 D B
1440 936 1493 970 C A
1256 816 1274 828 D A
1296 842 1344 874 C C
1130 734 1147 746 D C
HIGH / LOW HEAT CFM
TM(8,L)V060A12MP11C TM(8,L)V080B12MP11C Jumper Settings
High Low High Low HEAT Tap ADJ Tap*
1111 963 1480 1284 A Any
988 825 1317 1100 B Any
889 722 1185 963 C Any
808 642 1077 856 D Any
TM(8,L)V080C16MP11C TM(8,L)V100C16MP11C Jumper Settings
High Low High Low HEAT Tap ADJ Tap*
1480 1289 1851 1604 A Any
1317 1100 1646 1375 B Any
1185 960 1481 1204 C Any
1077 855 1347 1070 D Any
TM(8,L)V100C20MP11C TM(8,L)V120C20MP11C Jumper Settings
High Low High Low HEAT Tap ADJ Tap*
1851 1604 2220 1925 A Any
1646 1375 1975 1651 B Any
1481 1204 1778 1444 C Any
1347 1070 1616 1284 D Any
All CFM’s are shown at 0.5” w.c. external static pressure.These units have variable speed motors that automatically adjust to provide constant CFM from 0.0” to 0.6” w.c.
static pressure. From 0.6” to 1.0” static pressure, CFM is reduced by 2% per 0.1” increase in static. Operation on duct systems with greater than 1.0” w.c. external static
pressure is not recommended.
NOTE: At some settings, LOW COOL and/or LOW HEAT airflow may be lower that what is required to operate an airflow switch on certain models of electronic air clean-
ers. Consult the instructions for the electronic air cleaner for further details.
* The ADJ “D” tap should not be used.
