54
1
2
Take the metallic plates that hold the handlebar in position.
The rounded edge of the threaded one will face up.
Insert the M6 screws into the the threaded holes with a 3 millimiter
Allen key, but without letting them surpass the contact surface of
the plate. Make sure threadlocker is attached to the screws.
3
4
Holding the plates together, insert the assembly into the handlebar.
Bottom view of the assembly inserted into the handlebar.
