USB 2.0 connectors
These connectors are for USB 2.0 ports. Connect the USB module
cable to any of these connectors, then install the module to a
slot opening at the back of the system chassis. These USB
connectors comply with the USB 2.0 specification that supports
up to 480Mbps connection speed.
Front panel audio connector
This connector is for a chassis-mounted front panel audio I/O
module that supports either High Definition Audio or AC`97
audio standard. Connect one end of the front panel audio I/O
module cable to this connector.
痲簊 B365M-PLUS V21/BATTLE-AX B365M-PLUS V21
36
