colt 1911 - Lock, Magazine Catch

R
.003
-
+
2X R
.000
.140
MAX
.154
.091
-
.015
+.000
.003
.035
- .000
+.005
+.000
-
.004-
.038
.047
.00
-
+
.03
.090
.000
.000+
.004
.66
.16
-
SPHER R
R.013
MAX
.000+
.003
.06
2X R.01
.143
- .010
+
2X R.01 MAX
.01
- .00
+.02
45°±5° X
08/31/2010
•
B
IS PROHIBITED.
R Benson
WEIGHT: 0.00 LB
5013218
―
ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF
M1911-A1 REDUX
MFG
ENGRG
DRAWN
HEAT TREAT
SHEET 1 of 1
DIM & TOL IAW ASME Y14.5 - 1994.
SCALE: 6:1
THIRD ANGLE PROJECTION
1st MADE FOR:
LOCK, MAGAZINE CATCH
. Benson Consulting, LLP
Benson Consulting, LLP
STEEL, 1117 ASTM A108
MODELED
CASE DP .003-.005, RH C 48-52
08/16/2010 R Benson
DO NOT SCALE DRAWING
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE AND INTELLECTUAL PROPERTY OF
1-704-860-1202
Benson Consulting, LLP
REV
DWG NO
SIZE
TITLE
FINISH
MATERIAL
DATEBY
QA
X
PARA 5.3.1.2 OF MIL-STD-171
Gastonia, NC 28054
•
rhbenson@earthlink.net
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN INCHES.
TOLERANCE: ANGULAR .5 ,
2 PL .01, 3 PL .005, 4 PL .0005,
SYMM & CONC: 1/2 FEATURE TOL.
FAB FINISH: 125 MICROINCH.
BRK/FIL SHARP COR .005 MAX.
REVISION HISTORY
REV DESCRIPTION DATE APPRVD
