colt 1911 - Bow, Trigger

A
A
.630
.199
BOTH SIDES
.44
.000
-
2X R
+
.004
±.010
.010
.000
.11
-
.80
.06
+
R
2.587
.77
.224
- .004
+.000
74.5°
.276
.000
2X R
.006
+
-
+
1.379
-
.000
.005
.003
+.000
.000+
.005-
.555
.033
-
4X R.025
- .010
+.000
VIEW A-A
.006
+
.098
-
.000
+.010
-
.000
+.000
- .005
.232
.356
.218
2X R.02
- .01
+.00
REVISION HISTORY
REV DESCRIPTION DATE APPRVD
5153126
HEAT TREAT
09/01/2010
R Benson
THIRD ANGLE PROJECTION
DIM & TOL IAW ASME Y14.5 - 1994.
―
ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF
ENGRG
DRAWN
MODELED
IS PROHIBITED.
SHEET 1 of 1
WEIGHT: 0.01 LBSCALE: 2:1
X
STEEL, 1018, ASTM A108
Benson Consulting, LLP
Benson Consulting, LLP.
1st MADE FOR: M1911-A1 REDUX
BOW, TRIGGER
B
07/30/2010 R Benson
DO NOT SCALE DRAWING
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE AND INTELLECTUAL PROPERTY OF
1-704-860-1202
Benson Consulting, LLP
REV
DWG NO
SIZE
TITLE
FINISH
MATERIAL
DATEBY
QA
MFG
PARA 5.3.1.2 OF MIL-STD-171
••
rhbenson@earthlink.net Gastonia, NC 28054
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN INCHES.
TOLERANCE: ANGULAR .5 ,
2 PL .01, 3 PL .005, 4 PL .0005,
SYMM & CONC: 1/2 FEATURE TOL.
FAB FINISH: 125 MICROINCH.
BRK/FIL SHARP COR .005 MAX.
