4
47
31
SECTION A-A
32
35
36
37
33
34
2
24
30
5
1127
29
12
28
17
10
3
18
1613
8
9
38 14 15
7
6
48
1
SCALE 3 : 1
SECTION C-C
20
21
19
TAB LOCKS INTO CIRCULAR
SLOT IN ITEM 1, RECEIVER
IS PROHIBITED.
M1911-A1 REDUX
N/A
A
B
C
D D
C
B
A
8
7 6 5 4 3 2 1
8
7 6 5 4
SYMM & CONC: 1/2 FEATURE TOL.
FAB FINISH: 125 MICROINCHES.
BRK/FIL SHARP COR .01 MAX.
DIM & TOL IAW ASME Y14.
ENGRG
R Benson 09/29/2010
R Benson 09/25/2010
SHEET 1 of 1 WEIGHT: 3.01 LBSCALE: 3:2
- BC10092701 D
Gastonia, NC 28054
M1911-A1 REDUX
N/A
Benson Consulting, LLP
3
1
5 - 1994.
THIRD ANGLE PROJECTION
DO NOT SCALE DRAWING
MODELED
DRAWN
MFG
QA
BY DATE
MATERIAL
FINISH
SIZE REVDWG NO.
ASSEMBLY
―
1st MADE FOR:
1-704-860-1202
•
• rhbenson@earthlink.net
TITLE
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN INCHES.
TOLERANCES: ANGULAR ±.5°,
2 PL ±.01, 3 PL ±.005, 4 PL ±.0005.
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE AND INTELLECTUAL PROPERTY OF
Benson Consulting, LLP
.
ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF
Benson Consulting, LLP
HEAT TREAT
.0625 .0005 MATCH DRILL AT ASSY THRU EXISTING HOLE IN ITEM 1,
ITEM
2.
BOM Table
RECEIVER, AND LONG LEG OF ITEM 22, EJECTOR, PRIOR TO PRESS-FIT
ITEM 23, EJECTOR PIN.
RECEIVER
QTY.
1.
REVISION HISTORY
ZONE
NOTES:
REV
PartNo
2
DESCRIPTION
1 1 6535359
PISTOL IS SHOWN IN CONDITION ONE, COCKED, LOCKED AND LOADED.
DESCRIPTION DATE APPRVD
1 6147780 TRIGGER ASSEMBLY
3 1 6008602 SPRING, SEAR [MFA]
4 1 5503841 HOUSING, MAINSPRING
5 1 5013213 PIN, RETAINER, MAINSPRING HOUSING
6 1 5013208 MAINSPRING
7 1 5013209 CAP, MAINSPRING
8 1 BC10091602 PIN, MAINSPRING CAP
9 1 5013212 PIN, MAINSPRING HOUSING
10 1 7268068 SEAR
11 1 6008603 DISCONNECTOR
12 1 5013211 PIN, SEAR
13 1 5503839 HAMMER
14 1 6008600 STRUT, HAMMER
15 1 5013207 PIN, HAMMER STRUT
16 1 5013206 PIN, HAMMER
17 1 6501828 SAFETY, GRIP
18 1 5503840 LOCK, SAFETY
19 1 6008609 CATCH, MAGAZINE
20 1 5013217 SPRING, MAGAZINE CATCH
21 1 5013218 LOCK, MAGAZINE CATCH
22 1 6019024 EJECTOR
23 1 5013203 PIN, EJECTOR
24 1 7790314 SLIDE
BOM Table
ITEM QTY. PartNo DESCRIPTION
25 1 5013197 SIGHT, FRONT
26 1 5013196 SIGHT, REAR
27 1 5013204 SPRING, FIRING PIN
28 1 6008599 PIN, FIRING
29 1 6008598 EXTRACTOR
30 1 5013205 STOP, FIRING PIN
31 1 7791193 BARREL
32 1 6008596 BUSHING, BARREL
33 1 7267771 LINK, BARREL
34 1 5013199 PIN, BARREL LINK
35 1 5013201 PLUG, RECOIL SPRING
36 1 5013200 SPRING, RECOIL
37 1 6008597 GUIDE, RECOIL SPRING
38 1 6008595 STOP, SLIDE
39 1 6008594 TUBE, PLUNGER
40 1 5013193 PLUNGER, SLIDE STOP
41 1 5013194 SPRING, PLUNGER
42 1 5013195 PLUNGER, SAFETY LOCK
43 4 6019022 BUSHING, STOCK SCREW
44 1 5564062 STOCK, RH, PLASTIC
45 4 6019023 SCREW, STOCK
46 1 BC10090501 STOCK, LH, PLASTIC
47 1 NONE CARTRIDGE - REFERENCE ONLY
48 1 BC10091603 MAGAZINE ASSY
43
REF
4646
38
22
SEE NOTE 2
2326
18
25
REF
B B
C
C
D
D
4544 43
A
A
SECTION B-B
29
NOTICE GRASP ON
CARTRIDGE CASE
SCALE 3 : 1
SECTION D-D
41
39 42
40
