.03
AFTER CRIMPING.
MOVEMENT TO EACH OTHER
FLUSH
PAD, TRIGGER
5153127
CRIMP THESE TWO AREAS
SUFFICIENT TO LOCK PAD TO
BOW WITHOUT PERCEPTABLE
5153126
BOW, TRIGGER
.432
THIRD ANGLE PROJECTION
6147780
HEAT TREAT
09/12/2010
R Benson
DIM & TOL IAW ASME Y14.5 - 1994.
―
ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF
Gastonia, NC 28054
ENGRG
DRAWN
MODELED
IS PROHIBITED.
SHEET 1 of 1
WEIGHT: 0.03 LBSCALE: 2:1
X
PER CALLOUT
Benson Consulting, LLP
Benson Consulting, LLP.
1st MADE FOR: M1911-A1 REDUX
TRIGGER ASSEMBLY
B
07/30/2010 R Benson
DO NOT SCALE DRAWING
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE AND INTELLECTUAL PROPERTY OF
1-704-860-1202
Benson Consulting, LLP
REV
DWG NO
SIZE
TITLE
FINISH
MATERIAL
DATEBY
QA
MFG
SEE NOTE 1
••
rhbenson@earthlink.net
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN INCHES.
TOLERANCE: ANGULAR .5 ,
2 PL .01, 3 PL .005, 4 PL .0005,
SYMM & CONC: 1/2 FEATURE TOL.
FAB FINISH: 125 MICROINCH.
BRK/FIL SHARP COR .005 MAX.
REFINISH, IF NECESSARY AFTER CRIMPING,1.
IAW PARA 5.3.1.2 OF MIL-STD-171.
NOTES:
REVISION HISTORY
REV DESCRIPTION DATE APPRVD
