colt 1911 - Bushing, Barrel

.436
-.006
+.000
.750
-.015
+.000
66°±2°
76°±1°
SECTION A-A
.000+
.003
.003+
.115
- .000
.112
-
2X R.010
- .005
+.000
SECTION B-B
63
90° .610
- .006
.091
.000
+.015 .000
- - .005
+
.83
-
.581
.002
.58
+
.000
.000+
±5° .696
R.015
- .005
+.000
: STEEL, IC4140, ASTM A732.CAST
AUSTENITIC GRAIN SIZE 6 OR FINER.
NOTES:
MATERIAL:1.
WROUGHT: STEEL, 4140, ASTM A108;
REVISION HISTORY
REV DESCRIPTION DATE APPRVD
6008596
HEAT TREAT
RH C 43.5-50
09/07/2010R Benson
THIRD ANGLE PROJECTION
DIM & TOL IAW ASME Y14.5 - 1994.
―
ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF
ENGRG
DRAWN
MODELED
IS PROHIBITED.
SHEET 1 of 1
WEIGHT: 0.03 LBSCALE: 3:2
X
SEE NOTE 1
Benson Consulting, LLP
Benson Consulting, LLP.
1st MADE FOR: M1911-A1 REDUX
BUSHING, BARREL
B
07/28/2010 R Benson
DO NOT SCALE DRAWING
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE AND INTELLECTUAL PROPERTY OF
1-704-860-1202
Benson Consulting, LLP
REV
DWG NO
SIZE
TITLE
FINISH
MATERIAL
DATEBY
QA
MFG
PARA 5.3.1.2 OF MIL-STD-171
••
rhbenson@earthlink.net Gastonia, NC 28054
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN INCHES.
TOLERANCE: ANGULAR .5 ,
2 PL .01, 3 PL .005, 4 PL .0005,
SYMM & CONC: 1/2 FEATURE TOL.
FAB FINISH: 125 MICROINCH.
BRK/FIL SHARP COR .005 MAX.
30°±1°
2X R.903
R.197
- .005
+.000
2X R.05
.23R
.23R
R.396
- .006
+.000
A
A
B
B
