colt 1911 - Guide, Recoil Spring

.27
R.250 SWAGE
.187
REVISION HISTORY
REV DESCRIPTION DATE APPRVD
DIM & TOL IAW ASME Y14.5 - 1994.
THIRD ANGLE PROJECTION
X
RH C 35-40
HEAT TREAT
―
ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF
M1911-A1 REDUX
•
QA
MFG
ENGRG
DRAWN
6008597
MODELED
R Benson
IS PROHIBITED.
•
PARA 5.3.1.2 OF MIL-STD-171
Gastonia, NC 28054 rhbenson@earthlink.net
RECOIL SPRING
GUIDE,
1st MADE FOR:
SHEET 1 of 1
SCALE: 2:1 WEIGHT: 0.02 LB
09/07/2010
08/12/2010 R Benson
DO NOT SCALE DRAWING
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE AND INTELLECTUAL PROPERTY OF
1-704-860-1202
Benson Consulting, LLP
REV
DWG NO
SIZE
TITLE
FINISH
MATERIAL
DATEBY
B
STEEL, 1141, ASTM A311
.
Benson Consulting, LLP
Benson Consulting, LLP
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN INCHES.
TOLERANCE: ANGULAR .5 ,
2 PL .01, 3 PL .005, 4 PL .0005,
SYMM & CONC: 1/2 FEATURE TOL.
FAB FINISH: 125 MICROINCH.
BRK/FIL SHARP COR .005 MAX.
.624
+
.19
.02
- .00
.36R
R
.09
-
.000+
.006
2X R
.655
- .006
+.000
A
A
SECTION A-A
B
.005
+.000
.448
-
45°
- 0°
+5°
X
.010-
R.033
.010-
+.000
+.000
.03
R
.025
-
.088
.336
-
.005
+.000
.000+
.005
+.000
.010-
1.745
.27
.095
- .010
+.000
DETAIL B
SCALE 4 : 1
R.050
- .005
+.000
