colt 1911 - Pin, Firing

2.296
-.006
+.000
.515
-.000
+.015
MATERIAL: STEEL, 1144, ASTM A108;1.
AUSTENITIC GRAIN SIZE 7 OR FINER.
NOTES:
REVISION HISTORY
REV DESCRIPTION DATE APPRVD
6008599
HEAT TREAT
RH A 70.5-73.5
09/09/2010
R Benson
THIRD ANGLE PROJECTION
DIM & TOL IAW ASME Y14.5 - 1994.
―
ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF
ENGRG
DRAWN
MODELED
IS PROHIBITED.
SHEET 1 of 1
WEIGHT: 0.01 LBSCALE: 3:1
X
SEE NOTE 1
Benson Consulting, LLP
Benson Consulting, LLP.
1st MADE FOR: M1911-A1 REDUX
PIN, FIRING
B
08/13/2010 R Benson
DO NOT SCALE DRAWING
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE AND INTELLECTUAL PROPERTY OF
1-704-860-1202
Benson Consulting, LLP
REV
DWG NO
SIZE
TITLE
FINISH
MATERIAL
DATEBY
QA
MFG
PARA 5.3.1.2 OF MIL-STD-171
••
rhbenson@earthlink.net Gastonia, NC 28054
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN INCHES.
TOLERANCE: ANGULAR .5 ,
2 PL .01, 3 PL .005, 4 PL .0005,
SYMM & CONC: 1/2 FEATURE TOL.
FAB FINISH: 125 MICROINCH.
BRK/FIL SHARP COR .005 MAX.
.0294 : 1)(
63
.01
R
.02
+.00
.152
-
R.03
2X R.015 MAX
- .005
+.000.000+
.002-
.000+
.165
-
.00
.010-
.165
-
+
)
.153
.000
SPHER R (
.125
.56
.091
+
-
.000+
.004
.0455
X 22
.03
.004
.20
- .01
+.00
.216
- .004
+.000
63
