colt 1911 - Strut, Hammer

2.015
-.010
+.000
.63±.03.13
NOTES:
MATERIAL: STEEL, 1144, ASTM A108;1.
AUSTENITIC GRAIN SIZE 7 OF FINER.
REVISION HISTORY
REV DESCRIPTION DATE APPRVD
THIRD ANGLE PROJECTION
B
RH A 70.5-73.5
6008600
R Benson
DIM & TOL IAW ASME Y14.5 - 1994.
HEAT TREAT
―
ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF
ENGRG
DRAWN
IS PROHIBITED.
X
•
SHEET 1 of 1
SCALE: 3:1 WEIGHT: 0.01 LB
SEE NOTE 1
Benson Consulting, LLP
Benson Consulting, LLP.
Gastonia, NC 28054 rhbenson@earthlink.net
•
PARA 5.3.1.2 OF MIL-STD-171
MODELED 08/18/2010 R Benson
DO NOT SCALE DRAWING
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE AND INTELLECTUAL PROPERTY OF
1-704-860-1202
Benson Consulting, LLP
REV
DWG NO
SIZE
TITLE
FINISH
MATERIAL
DATEBY
QA
MFG
09/09/2010
1st MADE FOR: M1911-A1 REDUX
STRUT, HAMMER
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN INCHES.
TOLERANCE: ANGULAR .5 ,
2 PL .01, 3 PL .005, 4 PL .0005,
SYMM & CONC: 1/2 FEATURE TOL.
FAB FINISH: 125 MICROINCH.
BRK/FIL SHARP COR .005 MAX.
1.618
.010
-
SPHER R (
-
.000
.010
.150
R.300
.406R
.618
.054
.107
1.395R
.113
+
.100
+
1.186
)
2.134R
R
.000
.096
- .000
+.003
THRU
60 5 X .116
BOTH SIDES
.107
- .005
+.000
