Comar Systems CSB200 - Product Specification

CSB200 Class B AIS
R2.0 41
• AIS: Rx channel 2 malfunction
• AIS: general failure
• AIS: no sensor position in use
• AIS: no valid SOG information
• AIS: no valid COG information
• AIS: 12V alarm
• AIS: 5V alarm
• AIS: Loss of serial interface integrity
• AIS: Background noise above -77dBm
ACK Message Format
Can be generated by a minimum keypad and display (MKD) unit, chart
plotter or other display device connected to the CSB200 to acknowledge
an alarm condition reported by the CSB200.
$--ACK,xxx*hh <CR><LF>
• xxx = Unique alarm number
RMC Message Format
Own vessels GPS information
$GPRMC,hhmmss.ss,A,llll.lllll,a,yyyyy.yyyyy,a,x.x,x.x,xxxxxx,x.x,a,a*hh<
CR><LF>
• hhmmss.ss = UTC of position fix
• A = Data Valid V = Navigation receiver warning
• llll.lllll,a = Latitude, N/S
• yyyyy.yyyyy,a = Longitude, E/W
• x.x = Speed over ground, knots
• x.x = Course over ground, degrees True
• xxxxxx = Date, ddmmyy
• A = Mode indicator Autonomous
CSB200 Class B AIS
R2.0 42
PRODUCT SPECIFICATION
Physical:
Dimensions 190 x 128 x 50 mm (L x W x H)
Weight 600g
Power: DC (9.6-15.6V)
Average power consumption 4W
Peak current rating 2A
GPS Receiver:
IEC 61108-1 compliant
Electrical Interfaces:
RS232 38.4kBaud bi-directional
RS422 NMEA 38.4kBaud bi-directional
Connectors:
Power
VHF Antenna connector BNC
GPS Antenna connector TNC
Interface RS232/RS422
VHF Transceiver:
Transmitter x 1
Receiver x 2
(One receiver time shared between AIS and DSC)
Frequency: 156.025 to 162.025 MHz in 25 kHz steps
