Combi Handy 4Cas Plus - Page 19

Installing the head support (Figure 5.2)
Loop the head support belt through the head support hole, the belt is tipped opposite
through the hole to attach. After it is installed, check if it is well secured to the seat
cushion or not by slightly pulling.
Reference for head support insert outlets
for child from around 1 month to 4 months for child from around 4 months to 7
months.
Installing Body & Hip support (Figure 5.3)
a. Using the supporting belts (upper position) of the Body & Hip support to pass thru
the holes of the seat cushion body support location.To fix the supporting belts by
opening the tail at the end.
b. Using the supporting belts (upper position) of the Body & Hip support to pass thru
the holes of the seat cushion hip support location.To fix the supporting belts by
opening the tail at the end.
c.The both sides of waist belts pass thru the upper holes of the Body & Hip support
The crotch belt pass thru the lower belt hole of the Body & Hip support.
Even the baby is under 3 years old, please stop using the
Body & Hip support if it does not fit the baby size. To take out the Body & Hip
support, follow the reverse steps of the installation.
To use with EggShock pad (Figure 5.4)
Putting into the head support to use.
The EggShock pad can be inserted into the head support of Dacco Seat to protect child
from the vibrations from the ground when strolling.
Insert the EggShock pad from the rear packet of the head support .
Putting into seat cushion to use. lnsert the Eggshock pad from the rear packet of the seat
cushion.
WARNING:
