- 4 -
Attaching, Adjusting and Removing the Tray, Snack Tray and Parent Tray
Attaching the Tray:
1. Align the tray to the grooves of the armrest and
slide the tray onto the chair while pulling the
release lever underneath the tray as shown in figure
8a.
2. The Snack Tray is placed over the grooves in the
Tray as shown in figure 8b.
Adjusting the Tray:
1. While pulling the release lever, slide the tray to one
of the three slots and release the lever. Gently pull
and push on the tray to ensure that it is locked into
the desired position.
Using the Parent Tray:
1. Pull out the Parent Tray from the side of the Tray as
shown in figure 8c.
Removing the Tray:
1. Pull the release lever underneath the tray and slide
off the seat.
Removing the Booster Seat
1. Press the Booster Seat downwards and then
pull up on the release levers and lift the Booster
Seat up off the seat base as shown in figure 7.
figure 7
figure 8a
figure 8b figure 8c
Release Lever
Under Tray
Attaching the Booster Seat
figure 6a figure 6b
1. Align the Booster Seat with the frame
as shown in figure 6a. Press the
Booster Seat down until it snaps into
place. Lift up on the Booster Seat to
ensure it is securely locked into place
as shown in figure 6b.
WARNING Ensure that all Booster seat straps are stowed
and away from seat base attachment area. Carefully check that
the Booster seat is attached properly to the seat base. Placing
a child in the Booster seat with seat base that is not properly
attached could possibly cause serious injury.
