According to age and weight of a child, there are two operating modes.
Seat Mode
Assembly steps
① Unfasten snap as shown.( Figure 2.5 )
② Pull out the strap from foot area of seat unit, secure the buttons on both sides in the
direction as shown.
( Figure 2.5-2.9 )
③ Pull the strap to one side to tighten and secure the seat back.
If unable to fasten snaps properly doing step ②, push the foot end of seat unit upwards
slightly and then repeat step ② again.
④ Line up and insert the hubs on both sides of the Seat into the hub slots on the Stroller
frame as shown.(Figure 3.2)
Infant Bed Mode
Steps are as follows:
① Pull the shoulder belt through the slots of seat back and seat cushion.
② Pull the waist strap through the slots of seat back and seat cushion.
③ Pull the crotch belt through the slot of seat panel and hide inside.
Reversing the Seat Unit ( Figure 4.1 )
①
Rotate the knob as shown with both hands, lift upwards and remove seat unit from the mounts.
② Turn the seat unit and re-insert into seat unit mounts.
③ Pull up the seat unit gently to check it is securely attached.
Note: Ensure to check seat position adjustment button is firmly secured when
carrying a child.
Note:
It is recommended to adjust the seat unit before assembling with stroller
frame for easy handling. Customer can also choose to adjust the seat
unit after assembling with stroller frame.
Note:
Seat mode is suitable for child over 6 months old or over 9 kg in weight.
The seat unit and the frame are not assembled together when shipped.
Steps of converting the seat unit into a baby bed: ( Figure 3.3 )
① Pull down the seat reclining buckle.
② Pull downwards seat position adjustment button until the seat unit is completely flat.
③ Release the button on one side of the seat unit.
④ Smooth flat the bottom of seat unit.
⑤ Fasten the snaps as shown.
WARNING: For the safety of the infant, do not carry the baby bed only.
Note: It is recommended to remove or hide safety straps when infant
bed mode is in use.
Note:
Infant bed mode is suitable for infant from newborn to 6 months old.
Note: Infant bed mode is restricted for use by infant who cannot sit up
unaided, roll or use arms and knees to support themselves only.
Maximum carrying weight: 9 kg.
