COMENDA RB200 - Control Panel

INSTRUCTIONS FOR THE USER
3
CONTROL PANEL
CONTROL PANELCONTROL PANEL
CONTROL PANEL
H2 H3 S3
Q1
H2 Pilot lamp "machine READY"
H3 Pilot lamp "machine WORKING"
Q1 Main switch
GREEN Machine off
RED Machine on / Start cycle
RED Machine on / Drain position (only mod. with drain pump)
S3 Push button "CYCLE START"
S Plug
