N
E
L
Q
Riscaldatore elettrico
Protettore termico
Trasformatore
Sensore di
temperatura
PCB
Marrone
Blu
Giallo/Verde
Relay
Relay
B
A
C
2.3 Breve introduzione della struttura del prodotto
4
(Nota: tutte le dimensioni sono in mm)
2.4 Diagramma cavi interni
SCHEMA ELETTRICO
A
B
C
D1
D2
30L
340
340
278
130-310 130-310 130-310 130-310
50L
450
450
278
80L
450
450
278
100L
450
450
278
610 607
812
977
D1
D2
