4
2.3 Brief introduction of product structure
2.4 Internal Wire Diagram
WIRING DIAGRAM
(Note:All dimensions are in mm)
N
E
L
Q
Heating Element
Thermal
Cut Out
Transformer
Temperature
Sensor
Power Panel
Brown
Blue
Yellow/Green
Relay
Relay
B
A
C
A
B
C
D1
D2
30L
340
340
278
130-310 130-310 130-310 130-310
50L
450
450
278
80L
450
450
278
100L
450
450
278
610 607
812
977
D1
D2
