ComfortStar CHH012CD-13 - Page 30

Part Code
CHH012CD-13(I)
1 Wall-Mounting Frame 01252384 1
2Rear Case
22202050
1
3 Evaporator Assy 010021811 1
4 Cross-Flow Fan 10352005 1
5 Ring of Bearing 76712015 1
6 Drain Hose 05232411 1
7 Water Tray 201820302 1
8 Swing Louver 10512041 1
9 Swing Linkage 10582439 1
10 Front Grill 01472004 1
11 Front Case 20002295 1
12 Screw Cap 24252007 3
13 Air Filter 11122440 2
14 Panel 20002828 1
15 Panel 20002831 1
16 Remote Control YB1B4F 30511010 1
17 Light Cover 22242031 1
18 Display Board 30545557 1
19 Display Cover 22432071 1
20 Shield Board 26112048 1
21 Guide Louver 26112043 1
22 Guide Louver 26112042 1
23 Step Motor MP28EA 15212105 1
24 Right Motor Clamp 26112429 1
25 Motor FN22P 15012061 1
26 Motor Bearing Holder 26152423
1
27 Electric Box 201021081 1
28 Electric Box Cover 222420175 1
29 Terminal Board T4B3A
42011233
1
30 Covering Plate
20102123
1
31 Main PCB 9H82 30039085 1
32 Room Sensor 15K 390000451 1
33 Tube Sensor 20K 390000591 1
34 Transformer 57X25F
43110257
1
35 Wire Clamp
71010003
1
36
Rear Clamp 26112430
1
No Description Qty
Components and Parts List of Indoor Unit
29
