Part Code
CHH012CD-13(O)
1 Front Panel 01533007 1
2 Clap Board 01233012 1
3 Reactor Box C 01413504 1
4 PFC Inductance 0.8mH/20A 99070120 1
5 Drainage Connecter 06123401 1
6 Reactor Support Assy 01203102 1
7 Overload Protector 00183003 1
8 Compressor C-6RZ092H1AB 00102004 1
9 Compressor Gasket 76713006 3
10 Bolt 70210007 3
11 Nut 70310011 3
12 Valve Support 01713041 1
13 Right Side Plate Assy 01303071 1
14 Valve 1/2" 07100006 1
15 Valve 1/4" 07100003 1
16 Capillary Assy 03103301 1
17 One Way Valve 07130103 1
18 4-Way Valve 430004032 1
19 4-way Rever-sing Valve Component 03023670 1
20 Electric Cover Assy 01413086 1
21 4-way Valve Coil 430004002 1
22 Terminal Board A 42010255 1
23 Electric Box 2 01413025 1
24 Electric Box 20113001 1
25 PCB W9M32A 30039155 1
26 Temperature Sensor 3900012123 1
27 Sensor 20K 39000071 1
28 Exhaust Gas Temperature Sensor 50K 39000016 1
29 Electric Box Cover 01413048 1
30 Rectifier S25VB60 46010602 1
31 Sensor Insert 42020063 1
32 Radiator 49010213 1
33 Rear Grill 01473030 1
34 Condenser Assy 0110350713 1
35 Top Cover Assy 01253261 1
36 Motor Support Assy 017030521 1
37 Motor FW30K 15013067 1
38 Axial Flow Fan 10333414 1
39 Nut 70310131 1
40 Front Grill 22413011 1
No Description Qty
Components and Parts List of Outdoor Unit
