1. Product Performance
3
- This series of electric wheelchairs is powered by a Li-Ion battery that
supplies power to a DC drive motor(s). Users control the direction and
adjust the speed by using an analog joystick controller. This wheel-
chair is suitable for use at low speeds, on good road conditions, and
moderate slopes.
Performance Parameters and Technical Specs, X-6
Overall size 40” x 24.5” x 38” (1010x625x970mm)
Fold size 28.5“ x 18” x 30” (725x455x765mm)
Seat size* 17.5” x 17” (450x430mm)
Net Weight 53 lbs (24 kg) without battery
Net Weight 59.5 lbs (27 kg) with battery
Speed (0.62 mph - 3.7 mph (1 - 6km/h) Max 4 mph
Seat height 20” (510mm)
Armrest height 9” (230mm), from cushion
Backrest height 15.5” (395mm)
Max loading weight 286 lbs (130 kg)
Front wheel diameter 8 inch (200 mm)
Rear wheel diameter 12 inch (300 mm)
Battery 12AH Li-ion / 20 AH Li-ion
Motor x 2 PCs DC 24V / 250W X 2 pcs
Battery charge AC 220 (110V) ±10% 50-60HZ, 1.5 - 5A
Control 24V 35A
Max distance** 10 miles (15 km) / 16 miles (25 km)
Degree of protection IPX3
Max safe slope 10°
Turning radius ≤47 inches (≤1.2m)
Static stability 10°
Reversing width ≤59 inches (≤1.5m)
Climbing angle 10°
Tire pressure 2 kg f/㎡
Obstacle climbing 2 inches (50mm)
* seat width is the distance between armrests
** varies based on weight, incline, speed factors
