1. Product Performance
3
- This series of electric scooter is powered by a Li-Ion battery that sup-
plies power to a DC drive motor(s). Users control the direction and
adjust the speed by using an analog speed controller. This scooter is
suitable for use at low speeds, on good road conditions, and moder-
ate slopes.
Performance Parameters and Technical Specs, Z-1
Overall size 43” x 20.5” x 38” (1100x520x970mm)
Fold size 43“ x 20.5” x 20” (1100x520x510mm)
Seat size* 16.5” x 15” (420x380mm)
Net Weight 90 lbs (40.8 kg) without battery
Net Weight 98 lbs (44.5 kg) with battery
Speed (0.62 mph - 3.7 mph (1 - 8km/h) Max 5 mph
Seat height 18.5” (460mm) from ground
Armrest height 9” (230mm), from cushion
Backrest height 15.5” (395mm)
Max loading weight 330 lbs (150 kg)
Front wheel diameter 7.5 inch (190 mm)
Rear wheel diameter 8.5 inch (216 mm)
Battery 12AH Li-ion
Motor DC 24V / 250W
Battery charge AC 220 (110V) ±10% 50-60HZ, 1.5 - 5A
Controller DC 18.5V-30.5V 25A MAX
Max distance** 13 miles (20 km)
Degree of protection IPX3
Max safe slope 10°
Turning radius ≤47 inches (≤1.2m)
Static stability 10°
Reversing width ≤59 inches (≤1.5m)
Climbing angle 12v°
Ground clearance 2 inches (50mm)
Obstacle climbing 2 inches (50mm)
* seat width is the distance between armrests
** varies based on weight, incline, speed factors
